Product Description
Dynamic automatic dosing system is an automatic batching device, that is usually used in the process of BB fertilizer, organic fertilizer, and compound fertilizer production. It is one of the main components in fertilizer production. This machine is used for weighing and dispensing various raw materials instead of manual weighing or volumetric metering. It is the guarantee of the content of precision fertilizer products.
Technical Data
| Capacity | 2-100tph or customized | Motor power | Min 1.1kw, customized |
| Accuracy | ±0.4% | Hopper size | 1200*1200mm |
| Controller | PLC controller | Material | Carbon steel or stainless steel |
Dynamic Automatic Dosing System Advantage
- Accuracy of weighing is within 0.4%, control accuracy is within 1%.
- The belt conveyor with sensors uses H beam as the main frame and uses steel channels as support legs, so have high strength and high stiffness.
- On both sides of the main frame and leg, there are switches to avoid the deviation of the belt.
- In order to prevent running deviation, the driven drum adopts a chevron rubber surface which has the faction of preventing off-tracking.
- Unique skirt hem tape can prevent the material from overflowing, and on the other hand, it can prevent the material from accumulating at the head and tail, making the weight reach its top condition.
